Name: Cost-Effective Stainless Steel Wire Rope Mesh with 1.6mm to 2.4mm Wire Thickness and 50mm to 100mm Mesh Eye Size for Plant Trellis
Brand: Anping Yuntong Metal Wire Mesh Co.,Ltd
SKU: YT--F-2075
Price: 15.00 USD
Availability: InStock

Cost-Effective Stainless Steel Wire Rope Mesh with 1.6mm to 2.4mm Wire Thickness and 50mm to 100mm Mesh Eye Size for Plant Trellis

Basic Information

Place of Origin:	Hebei,China
Brand Name:	Yuntong
Certification:	CE , SGS
Model Number:	YT--F-2075

Minimum Order Quantity:	10 Sqm
Packaging Details:	Package film for each piece,Several pieces packed in 1 carton for the green wall climbing mesh
Delivery Time:	5-8 Work Days
Payment Terms:	T/T,Western Union,PayPal,L/C
Supply Ability:	300Sqm/Week

Contact Now

Material:

Stainless Steel 304 , 316 , 316L

Wire Thickness:

1.6 Mm To 2.4 Mm

Rope Constructions:

7 X 7 , 7 X 19 , 1 X 19

Mesh Angle:

60 Degree

Mesh Eye Size:

50mm To 100 Mm Or Bigger

Mesh Shape:

Rhombus , Diamond

Mesh Style:

X-tend In Ferruled Type

Shipment:

Express ,air Or Sea

Application:

Green Wall , Plant Trellis ,Climbing Net

Highlight:

1.6mm to 2.4mm Wire Thickness Stainless Steel Wire Rope Mesh

50mm to 100mm Mesh Eye Size Wire Rope Plant Trellis

Stainless Steel 304/316/316L Ferrule Cable Mesh

Cost-Effective Stainless Steel Wire Rope Mesh For Aviary Zoo Mesh Customizable

Stainless Steel Wire Rope Mesh Specifications

Mesh Opening Size

1.2MM(3/64) (7 x 7)	1.6MM(1/16) (7 x 7)	2.0MM(5/64) (7 x 7)	2.4MM(3/32) (7 x 7)	3.2MM(1/8) (7 x 19)
20 x 35mm YT-1235
25 x 42mm YT-1225	YT-1625
30 x 52mm YT-1230	YT-1630	YT-2030
35 x 60mm YT-1235	YT-1635	YT-2035
38 x 66mm YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

Material of Stainless steel 304, 316, 316L

Material	Chemical Composition (%)
SS304	C:≤0.07, Si:≤1.0, Mn:≤2.0, Cr:17.0-19.0, Ni:8.0-11.0, S:≤0.03, P:≤0.035
SS316	C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0

Stainless Steel Wire Rope Mesh by Yuntong can also be tensioned into three-dimensional forms featuring funnel-like, cylindrical or spherical shapes. Stainless Steel wire rope plant trellis is custom manufactured in widths and lengths to suit your application. Finished diamond mesh style when stretched at 60 degree angle. Mesh sizes range from 20mm to 120mm or bigger with stainless cable diameters from 1.2mm to 4.0 mm.

Recommended Stainless Steel Wire Rope Mesh Specification For Climber Plant Trellis Mesh

Material	Cable Diameter	Hole Size	Normal Break
SS304/316/316L	3/32" (2.4MM)	2.5" x 2.5"	920LBS
SS304/316/316L	3/32" (2.4MM)	3" x 3"	920LBS
SS304/316/316L	3/32" (2.4MM)	4" x 4"	920LBS
SS304/316/316L	5/64" (2.0MM)	2.5" x 2.5"	676 LBS
SS304/316/316L	5/64" (2.0MM)	3" x 3"	676 LBS
SS304/316/316L	5/64" (2.0MM)	4" x 4"	676 LBS

Features Of Stainless Steel Wire Rope Mesh

High strength, strong toughness, free angles curving and fold, easy for transportation and installment
Can bear heavy snow and glae
Without toxic material, safety, environmental protection
