Name: Stainless Steel 304/316/316L Wire Rope Mesh with 60 Degree Mesh Angle and 1.6mm to 2.4mm Wire Rope for Plant Trellis
Brand: Anping Yuntong Metal Wire Mesh Co.,Ltd
SKU: YT--F-2075
Price: 15.00 USD
Availability: InStock

Stainless Steel 304/316/316L Wire Rope Mesh with 60 Degree Mesh Angle and 1.6mm to 2.4mm Wire Rope for Plant Trellis

Basic Information

Place of Origin:	Hebei
Brand Name:	Yuntong
Certification:	CE , SGS
Model Number:	YT--F-2075

Minimum Order Quantity:	10 Sqm
Packaging Details:	Package film for each piece,Several pieces packed in 1 carton
Delivery Time:	5-8 Work Days
Payment Terms:	T/T,Western Union,PayPal
Supply Ability:	300Sqm/Week

Contact Now

Product Name:

Wire Rope Climber Plant Trellis Mesh

Material:

Stainless Steel 304 , 316 , 316L

Wire Rope:

1.6 Mm To 2.4 Mm

Mesh Orientation:

Horizontal , Vertical

Mesh Shape:

Rhombus , Diamond

Rope Constructions:

7 X 7 , 7 X 19 , 1 X 19

Application:

Green Wall , Plant Trellis , Climbing Net

Mesh Angle:

60 Degree

Mesh Style:

X-tend In Ferruled Type

Highlight:

Stainless Steel 304/316/316L Wire Rope Mesh

60 Degree Mesh Angle Wire Rope Mesh

1.6mm to 2.4mm Wire Rope Plant Trellis Mesh

Stainless Steel Woven Protection Metal Wire Rope Mesh

High-quality stainless steel wire rope mesh designed for bird cage protection and safety applications. This durable mesh offers excellent strength and corrosion resistance.

Wire Rope Mesh Specifications

Hole Size (Opening)	1.2MM (3/64) (7*7)	1.6MM (1/16) (7*7)	2.0MM (5/64) (7*7)	2.4MM (3/32) (7*7)	3.2MM (1/8) (7*19)
20*35mm	YT-1235
25*42mm	YT-1225	YT-1625
30*52mm	YT-1230	YT-1630	YT-2030
35*60mm	YT-1235	YT-1635	YT-2035
38*66mm	YT-1238	YT-1638	YT-2038	YT-2438
40*69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50*86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60*104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70*120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76*131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80*138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90*154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100*173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120*206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

Material Specifications

Available in stainless steel grades: 304, 304L, 316, 316L

Grade	Chemical Composition (%)
SS304	C:≤0.07, Si:≤1.0, Mn:≤2.0, Cr:17.0-19.0, Ni:8.0-11.0, S:≤0.03, P:≤0.035
SS316	C:≤0.08, Si:≤1.00, Mn:≤2.00, P:≤0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0-18.0, Ni:12.0-15.0

Product Features

Made from high-quality stainless steel wires with skin-like flexibility
Can form flat surfaces or be tensioned into three-dimensional forms (funnel-like, cylindrical, spherical)
Custom manufactured to required widths and lengths
Creates diamond mesh pattern when stretched at 60-degree angle
Available in diagonal and irregular shapes
Suitable for both vertical and horizontal applications

Recommended Specifications for Climber Plant Trellis Mesh

Material	Cable Diameter	Hole Size	Normal Break
SS304/316/316L	3/32" (2.4MM)	2.5"*2.5"	920 LBS
SS304/316/316L	3/32" (2.4MM)	3"*3"	920 LBS
SS304/316/316L	3/32" (2.4MM)	4"*4"	920 LBS
SS304/316/316L	5/64" (2.0MM)	2.5"*2.5"	676 LBS
SS304/316/316L	5/64" (2.0MM)	3"*3"	676 LBS
SS304/316/316L	5/64" (2.0MM)	4"*4"	676 LBS

X-TEND Stainless Steel Mesh Advantages

X-TEND stainless steel mesh is lightweight, robust, and transparent. High-quality stainless steel cables and pressed ferrules create a load-bearing, flexible structure. The curvature in the opposite direction of the stainless steel cables provides exceptional robustness, allowing the mesh to withstand heavy loads.
