Name: Fall Prevention Black Oxide Finished Stainless Steel Wire Rope Mesh with 60 Degree Mesh Angle
Brand: Anping Yuntong Metal Wire Mesh Co.,Ltd
SKU: YT--F-F
Price: 21.00 USD
Availability: InStock

Fall Prevention Black Oxide Finished Stainless Steel Wire Rope Mesh with 60 Degree Mesh Angle

Basic Information

Place of Origin:	Hebei
Brand Name:	Yuntong
Certification:	CE , SGS
Model Number:	YT--F-F

Minimum Order Quantity:	10 Sqm
Packaging Details:	Package film for each piece,Several pieces packed in 1 carton
Delivery Time:	5-8 Work Days
Payment Terms:	T/T,Western Union,PayPal
Supply Ability:	300Sqm/Week

Contact Now

Material:

Stainless Steel 304 , 316 , 316L

Wire Rope:

1.2 Mm To 4.0 Mm

Rope Constructions:

7 X 7 , 7 X 19 , 1 X 19

Finished:

Black Oxide

Mesh Orientation:

Horizontal , Vertical

Mesh Shape:

Rhombus , Diamond

Application:

Animal Enclosure , Aviary Netting , Garden Fence , Etc

Mesh Angle:

60 Degree

Mesh Style:

X-tend Type

Highlight:

Fall Prevention Stainless Steel Wire Rope Mesh

Black Oxide Finished Wire Cable Rope Mesh

60 Degree Mesh Angle Stainless Steel Cable Mesh

Fall Prevention Stainless Steel Wire Cable Rope Mesh Net For Decorative Building

Product Overview

Stainless Steel Wire Cable Rope Mesh Net is manufactured from high-quality stainless steel or aluminum materials. Through specialized weaving, stretching, and stamping processes, this product combines exceptional tensile strength with elegant diamond-shaped openings, creating a perfect fusion of modern science and artistic design.

The mesh offers remarkable design flexibility in architectural applications, featuring graceful aesthetics while maintaining the indestructible properties of stainless steel construction.

Product Specifications

Hole Size (Opening)	1.2MM (3/64) (7 x 7)	1.6MM (1/16) (7 x 7)	2.0MM (5/64) (7 x 7)	2.4MM (3/32) (7 x 7)	3.2MM (1/8) (7 x 19)
20 x 35mm	YT-1235
25 x 42mm	YT-1225	YT-1625
30 x 52mm	YT-1230	YT-1630	YT-2030
35 x 60mm	YT-1235	YT-1635	YT-2035
38 x 66mm	YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

Material Specifications

Available in Stainless Steel 304, 316, 316L, and other grades:

Material	Chemical Composition (%)
SS304	C: ≤0.07, Si: ≤1.0, Mn: ≤2.0, Cr: 17.0-19.0, Ni: 8.0-11.0, S: ≤0.03, P: ≤0.035
SS316	C: ≤0.08, Si: ≤1.00, Mn: ≤2.00, P: ≤0.035, S: ≤0.03, Ni: 10.0-14.0, Cr: 16.0-18.5
SS316L	C: ≤0.03, Si: ≤1.00, Mn: ≤2.00, P: ≤0.045, S: ≤0.030, Cr: 16.0-18.0, Ni: 12.0-15.0

Product Features

Skin-like characteristics with exceptional flexibility
Can form flat surfaces or be tensioned into three-dimensional forms including funnel-like, cylindrical, or spherical shapes
Lightweight, robust, and transparent construction
Manufactured using high-quality stainless steel cables and pressed ferrules
Connected to load-bearing and flexible structures
Opposite-direction curvature creates exceptional robustness
Capable of withstanding heavy loads
