Stainless Steel Flexible Cable Wire Mesh Netting for Bird Aviary - 316 Marine Grade

Product Specifications

Attribute	Value
Rope Constructions	7 x 7 , 7 x 19
Material	High Grade AISI316
Finished	Ultrasonic Bath , Black Oxide
Wire Rope	1.2 mm to 4.0 mm
Mesh Type	Ferruled
Mesh Orientation	Horizontal , Vertical
Product Name	X-tend Cable Webnet Mesh Fence
Panel Sheet	Customized in width and length

Product Features

The netting is clipped to the cable
The mesh size and diameter can be modified
Can be made to customer orders and statically tested - especially suitable for facades
High strength, strong toughness, free-angles curving and fold, easy for transportation and installation
Anti-corrosive, resists rust, can be repeatedly used
Resists chewing by rodents and other pests (tensile strength approximately 100-110,000 PSI)
Can bear heavy snow and strong winds
Non-toxic material, safe and environmentally friendly
Lightweight, high-strength, never rusts, soft
Fatigue resistance, impact resistance, breaking force, rugged structure with lifespan over 30 years

Wire Rope Net Specifications

Hole Size (Opening)	1.2MM(3/64) (7 x 7)	1.6MM(1/16) (7 x 7)	2.0MM(5/64) (7 x 7)	2.4MM(3/32) (7 x 7)	3.2MM(1/8) (7 x 19)
20 x 35mm	YT-1235
25 x 42mm	YT-1225	YT-1625
30 x 52mm	YT-1230	YT-1630	YT-2030
35 x 60mm	YT-1235	YT-1635	YT-2035
38 x 66mm	YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

Additional Information

Manufactured from 316 'marine grade' stainless steel, the Webnet mesh system can be specified for any balustrade requiring a contemporary infill.

Wire Rope Net is custom manufactured in widths and lengths to suit your balustrade, railing or architectural application. Diagonal and irregular shapes can also be supplied.

Mesh sizes range from 25mm x 25mm to 250mm x 250mm with stainless cable diameters from 1.2mm to 3.2mm.

Mesh can be applied in either a vertical or horizontal direction, dependent on the balustrade or railing design and the required aesthetics.

Finished diamond mesh style when stretched at 60 degree angle.

Frequently Asked Questions

1. Advantage of Wire Rope Net

Unique design. 3D-structure, Flexible, Light weight, Corrosion resistant, Maintenance free. 10 years rust guaranteed.

2. 304 or 316 stainless steel?

Generally the 304 stainless steel is cheaper than 316 stainless steel. For flexible wire rope mesh, the main cost is process cost, so the cost of mesh between 304 and 316 is almost the same. We suggest choosing 316 stainless steel.

3. What is the difference with cable and opening?

The heavier cable or smaller opening, the more expensive the cost.

4. Is it safe?

Full mesh meets test under EN1263.1.2014.

5. How to install the mesh?

All of our pieces are manufactured with special edge design for easy self-installation.

Product Images

Tag:

Place of Origin:	Hebei
Brand Name:	Yuntong
Certification:	CE , SGS
Model Number:	YT-CM

Minimum Order Quantity:	10 Sqm
Packaging Details:	Carton Box or Wooden Case
Delivery Time:	5-8 Work Days
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	300Sqm/Week

Rope Constructions:	7 X 7 , 7 X 19	Material:	High Grade AISI316
Finished:	Ultrasonic Bath , Black Oxide	Wire Rope:	1.2 Mm To 4.0 Mm
Mesh Type:	Ferruled	Mesh Orientation:	Horizontal , Vertical
Product Name:	X-tend Cable Webnet Mesh Fence	Panel Sheet:	Customized In Width And Length
Highlight:	Stainless Steel Cable Mesh , 316 Marine Grade Wire Netting , Flexible Aviary Bird Netting
