SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh

Enclosures Webnet – A material such as Webnet is the ideal creative and functional alternative to fencing and bars. All over the world, increasing numbers of zoological gardens are using it as the resource of choice for new animal enclosures. Word of the positive experience gained with this material is gradually spreading among the experts. Webnet is safety-certified, weather-resistant and highly durable and requires little or no maintenance. Even the initial investment can be considered comparatively cost-effective.
Material of Cable Webnet : Stainless steel 304,304L,316,306L etc.

Animal Enclosure Wire Rope Mesh Specifications Sheet :

Hole Size (Opening)	1.2MM(3/64) (7 x 7 )	1.6MM(1/16) (7 x 7 )	2.0MM(5/64) (7 x 7 )	2.4MM(3/32) (7 x 7 )	3.2MM(1/8) (7 x 19 )
20 x 35mm	YT-1235
25 x 42mm	YT-1225	YT-1625
30 x 52mm	YT-1230	YT-1630	YT-2030
35 x 60mm	YT-1235	YT-1635	YT-2035
38 x 66mm	YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh 0

SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh 1

SS304	(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316	(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0

Finished diamond mesh style when it is stretched at 60 degree angle ;
Mesh can be applied in either a vertical or horizontal direction, again dependent on the design ;
Mesh sizes range from 20mm to 120mm or bigger with stainless cable diameters from 1.2mm to 4.0 mm.

Stainless Steel Wire Rope Mesh is custom manufactured to in widths and lengths to suit your architectural application. Finished diamond mesh style when it is stretched at 60 degree angle ; Diagonal and irregular shapes can also be supplied. Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics. SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh 2

All of our products are made from High Grade 316 Stainless Steel, offering many advantages, including:

316 "marine grade" stainless steel
Innovative, highly durable product
Black anodised or galvanised finish options
Great prices
Professional, friendly service
Pliable, high strength mesh system
Wide range of sizes available
UV and weather resistant
Fast turnaround

Applications :

Tag:

Place of Origin:	Hebei
Brand Name:	Yuntong
Certification:	CE , SGS
Model Number:	YT--F-1650

Minimum Order Quantity:	10 Sqm
Packaging Details:	Carton Box , Wooden Case
Delivery Time:	5-8 Work Days
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	300Sqm/Week

Name:	SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh SS304 SS316 Stainless Steel Wire Rope Mesh Zoo Safety Cable Mesh	Rope Constructions:	7 X 7
Mesh Shape:	Rhombus , Diamond	Application:	Zoo Mesh
Mesh Angle:	60 Degree	Wire Rope:	1.5mm , 1.6mm , 2.0mm
Mesh Style:	Ferruled , Knotted	Mesh Orientation:	Horizontal , Vertical
Panel Size:	Custom-Made
Highlight:	SS304 SS316 Wire Rope Mesh , Zoo Safety Cable Mesh , Zoo stainless steel ferrule rope mesh
