Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent

Basic Information
Place of Origin: China
Brand Name: YUNTONG
Certification: CE
Model Number: YT-F3060
Minimum Order Quantity: 5
Price: USD 5-25/m2
Packaging Details: wooden case
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 8000m2/week
Material: SUS 304 SUS 316 Wire Diameter: 1.2 Mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm
Size Of Hole: 25*25mm-300*300mm Height: Customized
Length: Customized Characteristic: Anti-corrosion Non-rusting Anti Acid And Alkali
Application: Protective, Fall Prevention Weave Style: Plain Weave,Ferruled,knotted/ferrule,Woven Or Ferruled
High Light:

Flexible Stainless Steel Rope Netting

,

Anti corrosion Stainless Steel Rope Netting

,

Flexibility Stainless Steel Rope Netting

Suspended safety stainless steel rope netting flexibility and Excellent



Stainless steel wire rope fence mesh is also known as safety netting system. It is widely used in slope reinforcement.The system,mainly made up of wire ,enjoy the basic functions to cover (initiative protection) and intercept (passive protection) so as to defend various geological disasters.



1. Specification as follows:
Material: ss304 ss316
Mesh type: 1.Woven 2. Ferrule mesh

CableStructure:7x7 and 7x19

CableDiameter:1/8", 3/32", 1/16", and 3/64".

Mesh Size:1"x 1", 1-1/2"x1-1/2", 2"x2", 3"x3", and 4"x4"

Height: general 0.5-30meter or customized.
Length: general 0.5-30meter or customized.
Shape: There are irregular shape, triangle parallelogram trapezoid etc.



Anping Yuntong Metal Wire Mesh Co.,Ltd

Flexible Stainless Steel Cable Mesh(Ferrule Type)

Mesh Aperture Wire diameter
OW X OH (mm) Inch 1.2 mm 1.5 mm 2.0 mm 3.0 mm 4.0 mm
3/64" 1/16" 5/64" 1/8" 0.157"
20 x 35 4/5×1.39 YT1220
25.4 x 44 1×1.73 YT1225 YT1525
35 x 61 1.37×24 YT1235 YT1535 YT2035
38 x 65.8 1-1/2×2.6 YT1235 YT1538 YT2038 YT3038
51 x 88.3 2×3.46 YT1251 YT1551 YT2051 YT3051 YT4051
60 x 105 2.4×4.16 YT1260 YT1560 YT2060 YT3060 YT4060
76 x 131.6 3×5.2 YT1276 YT1576 YT2076 YT3076 YT4076
90 x 156 3.5×6.15 YT1290 YT1576 YT2090 YT3090 YT4090
102 x 176.7 4×6.9 YT20100 YT15100 YT20100 YT30100 YT40100
120 x 210 4.75×8.23 YT12120 YT15120 YT20120 YT30120 YT40120
160 x 280 6.3 x 11 YT12160 YT15160 YT20160 YT30160 YT40160
180 x 315 7.08 x 12.4 YT12180 YT15180 YT20180 YT30180 YT40180
200 x 350 7.87 x 13.78 YT12200 YT15200 YT20200 YT30200 YT40200
250 x 450 9.84 x 17.7 YT12250 YT15250 YT20250 YT30250 YT40250
300 x 525 11.8 x 20.67 YT12300 YT15300 YT20300 YT30300 YT40300



Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 0



2. cable structures and mesh type:



1. Knotted mesh is a kind of plain weave, each warp wire rope crosses alternately above and below each weft wire rope. Warp and weft wire ropes generally have the same diameter.



2.Ferruled mesh is of the same physical properties with the knotted mesh, the only difference is in the combination style, the stainless wire rope are combined by the ferrules which are made of the same grade stainless steel.


Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 1

Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 2
3. Introduce:

The mesh has strong tensile strength and high flexibility,high transparence and wide span. The flexible s.s. cable mesh has unreplacable advantages compared with other mesh products in many aspects like practicability, security, aesthetic property and durability etc.


Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 3

4.Application:

It widely used in the following areas: Fence, Garden fence, Aviary Mesh, Bird Netting,Animal Enclosure, Zoo Mesh,Agriculture,Residential Fence, stair railing, balustrade infill, architectural surface plant climbing net, Etc.



Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 4

5. Advantage:

1.The netting is clipped to the cable,
2. The mesh size and diameter can be modified
3. It can be made to customer orders and statically tested – especially suitable for facades
4. High strength, strong toughness, free-angles curving and fold, easy for transportation and installment.
5. Anti-corrosive, resist the rust, can be repeated use.
6. Resists chewing by rodents and other pests (tensile strength approximately 100-110,000 PSI)
7.This product can bear the heavy snow and the gale very much.
8. without toxic material, safety, environmental protection.

 Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 5

6. Accessory:

Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 6

7. Packing and Delivery:
Packing: Paper carton, wooden case
Delivery: by FedEx, DHL, UPS, TNT EMS, by air, Door-to Door or by sea.
Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 7



8. Company:



Anping Yuntong Metal Wire Mesh Co., Ltd. is an exporter and manufacturer of series wire mesh and industrial wire. Located in the native land of wire mesh in China. Our company's main products: various materials, fencing wire mesh, zoo mesh, rope mesh, aviary mesh,metal curtain,aluminum decorative mesh. Our products with complete specifications and sophisticated quality are mainly exported to the United States, Germany, South Korea, Belgium, and some Southeast Asian countries and regions. We have established long-term and friendly relationships with suppliers, and got trust from users at home and abroad.

Yuntong aims to become one of the first-class companies integrating scientific research, production and management together. Our goods are high in quality at favorable prices. We produce and supply metal wire mesh according to ISO9001 Quality Standards. 90% of our products are for export and sell well in the USA, Germany, Japan, Canada, South Korea, and other countries and regions.

Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 8 Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 9

Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 10



9. Factory :



Suspended Safety Stainless Steel Rope Netting Flexibility And Excellent 11
