Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design

Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design
Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design
Basic Information
Place of Origin: Hengshui ,Hebei ,China
Brand Name: Yuntong
Certification: CE , SGS
Model Number: YT-B-021
Minimum Order Quantity: 10 Square meters
Packaging Details: Architectural wire rope mesh available packaging : plastic film , water-proof fabric , carton box and wooden case
Delivery Time: About 5-8 Work Days
Payment Terms: T/T,Western Union,PayPal,L/C
Supply Ability: 300 square meters per week
Contact Now
Material: Stainless Steel 316 Cable Wire Diameter: 1.5mm , 1.6mm
Product Name: 316 Stainless Steel Architectural Metal Mesh Mesh Aperture: From 20mm To 200mm Or Bigger
Type: Knotted And Ferruled Mesh Width: As Your Need
Mesh Orientation: Horizontal And Vertical
Highlight:

stainless steel architectural mesh

,

metal wire mesh facade cladding

Modern Architectural Wire Mesh - High End Design 316 Stainless Steel Metal Mesh
316 Stainless Steel Architectural Metal Mesh Specifications
Cable Construction Cable Diameter Mesh Hole Size (W x H) Breaking Strength (KN)
7x19 1/8" (3.2mm) 4.75" x 4.75" (120x120mm) 7.38
7x19 1/8" (3.2mm) 4" x 4" (102x102mm) 7.38
7x19 1/8" (3.2mm) 3.6" x 3.6" (90x90mm) 7.38
7x19 1/8" (3.2mm) 3" x 3" (76x76mm) 7.38
7x19 1/8" (3.2mm) 2" x 2" (51x51mm) 7.38
7x7 3/32" (2.4mm) 4" x 4" (102x102mm) 4.18
7x7 3/32" (2.4mm) 3.6" x 3.6" (90x90mm) 4.18
7x7 3/32" (2.4mm) 3" x 3" (76x76mm) 4.18
7x7 3/32" (2.4mm) 2.4" x 2.4" (60x60mm) 4.18
7x7 3/32" (2.4mm) 2" x 2" (51x51mm) 4.18
Additional sizes and specifications available upon request.
Product Overview
We are a professional manufacturer of stainless steel wire woven rope mesh with over 10 years of experience. Our 316 stainless steel architectural metal mesh is known for its high quality, durability, and aesthetic appeal.
Key Features
  • Premium 316 stainless steel construction for superior corrosion resistance
  • Available in various cable constructions (7x7, 7x19) and diameters
  • Customizable mesh sizes to meet specific architectural requirements
  • High breaking strength for structural applications
  • Polished stainless steel surface for elegant appearance
Product Specifications
Product Name 316 Stainless Steel Architectural Wire Mesh
Wire Diameter 1.5mm, 1.6mm (other sizes available)
Cable Construction 7x7, 7x19
Dimensions Custom width and length available
Surface Treatment Stainless steel polished
Modern Architectural Wire Mesh with 20mm to 200mm Aperture and Horizontal Vertical Mesh Design 0
Dear Customer:
If you have any questions or special requirements, please feel free to contact us. Your satisfaction is our goal.
Thanks and best regards,
Anping Yuntong Metal Wire Mesh Co., Ltd.
