Home Decor Coil Mesh Drapery Decoration Room Dividers Flexible Curtain

Basic Information
Place of Origin: Hebei , P.R.China
Brand Name: Yuntong
Certification: CE
Model Number: YT-ACC-1266
Minimum Order Quantity: 10
Packaging Details: Wooden Case
Delivery Time: 5-8 Work Days
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 500Sqm/Week
Product Name: Metal Cascade Coil Drapery Material: Aluminum , Stainless Steel , Galvanized Wire
Wire Diameter: 0.8 Mm , 1.0 Mm 1.2 Mm , 1.5 Mm , 1.8 Mm , 2.0 Mm Hole Size: 4 Mm , 5 Mm , 6 Mm , 8 Mm , 10 Mm
Application: WIndow Curtain , Room Divider , Curtain Wall Drapery: 1.5 Time , 1.0 Time
Color: Gunmetal , Black , Bronze , Silver , Copper , Etc
High Light:

coil mesh drapery


cascade coil architectural drapery

 Metal Chain Link Mesh Fabric Coil Frapery Room Dividers For Decoration


Metal Cascade Coil Drapery  Instruction :

Home Decor Coil Mesh Drapery Decoration Room Dividers Flexible Curtain 0

Material Wire Dia Hole Size Weight  Surface
Stainless Steel 1.0 mm 5 mm 3.3kg/m2 Natural polished
Stainless Steel 1.0 mm 6 mm 3.5kg/m2 Natural polished
Stainless Steel 1.2 mm  6 mm 5.5kg/m2 Natural polished
Al-Mg Alloy 1.2 mm 4 mm 1.9kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 5 mm 1.5kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 6 mm 1.25kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 7 mm 1.2kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 8 mm 1.13kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 9 mm 0.85kg/m2 Paint-spray /Anodizing
Aluminium 1.0 mm 5 mm 1.5kg/m2 Paint-spray /Anodizing
Aluminium 1.2 mm  6 mm 2.5kg/m2 Paint-spray /Anodizing
Aluminium 1.2 mm 7 mm 2.0kg/m2 Paint-spray /Anodizing
Carbon Steel 0.9 mm 6 mm 4.0kg/m2 Paint-spray /Anodizing
Carbon Steel 1.0 mm 7 mm 5.5kg/m2 Paint-spray /Anodizing
Carbon Steel 1.2 mm 8 mm 6.0kg/m2 Paint-spray /Anodizing



1. The material: We have the Aluminum alloy and the SS 304, 316,
2. The wire diameter: 0.6mm-2.0mm
3. The mesh hole: 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, and as you need
4. The color of the mesh: We have more than hundreds of colors for your choice. You can also choose the color you favor.

Surface treatment :

1. Acid pickling:
This kind of treatment is most simple one. It mainly function is cleaning the oxide layer, and the metal curtain via this kind of treatment, the color will be the silvery white.

2. Anodic oxidation:
This one is a little complex; This one is working to enhance the rigidity and the wear-resisting property of the Al alloy. This one can color the metal curtain, and make the metal curtain more durable and beautiful.

3. Baking finish (This is the most popular one):
This kind is the simple one of coloring the metal curtain, it just paint mixing then put the metal curtain to the coating area to make the color.


This metal coil drapery is a new kind of building decoration materials, which are widely used in building elevation, divider, the ceiling, shade, balconies and corridors, shutter, staircases and airport access stations, hotels, museums, opera houses, concert halls, office buildings, exhibition halls, shopping malls, such as the high-grade internal and external decoration.

We have three different installation ways: U track, H track installation and stainless steel curtain rod installation.
H track can be applied as rippled strips to appear the effect of fluency. Because of high flexibility, it's easy to be bent into any shape or angle in order to conform to installation position condition which you need to install with copper or brass mesh coil curtain.
U track is a straight structure. It's difficult to bend because of exceptional structural design and high-quality control. U track can provide a good visual hang feeling for your copper and brass mesh coil curtain. If you need and desire an aesthetic appearance, U track will be a good choice.
Stainless steel curtain rod is is easy for installing with copper and brass mesh coil curtain on it. You can use shorter time to compete installation.
H track, U track are made from aluminum materials. Stainless steel curtain rod material conforms to AISI 316 materials group. These three installation ways can provide ideal solutions with excellent stability, strength and flexibility for you. You can custom according to your requirements.


Home Decor Coil Mesh Drapery Decoration Room Dividers Flexible Curtain 1Home Decor Coil Mesh Drapery Decoration Room Dividers Flexible Curtain 2

Home Decor Coil Mesh Drapery Decoration Room Dividers Flexible Curtain 3
